PVC-U Cable Tray-Supports & Accessories

Supports

Cantilever arms

  • Ordering Code Width A×B
    　 mm mm×mm
    CPCA100 For 75/100 75 x 50
    75 x 75
    100 x 50
    100 x 75
    CPCA150 For 150 150 x 50
    150 x 75
    CPCA200 For 200 200 x 50
    200 x 75
    200 x 100
    CPCA300 For 300 300 x 50
    300 x 75
    300 x 100

Steel - plastic coated

  • Ordering Code Width A×B
    　 mm mm×mm
    CPCAS300 For 300 300 x 50
    300 x 75
    300 x 100
    CPCAS400 For 400 400 x 50
    400 x 75
    400 x 100
    CPCAS500 For 500 500 x 100
    CPCAS600 For 600 600 x 100

Trapeze hangers

  • Ordering Code Width A B
    　 mm mm mm
    CPTH100 For 75/100 150 115
    CPTH150 For 150 200 165
    CPTH200 For 200 250 215
    CPTH300 For 300 350 315
    CPTH400 For 400 450 415
    CPTH500 For 500 550 515
    CPTH600 For 600 650 615

Stand-off brackets

  • Ordering Code Width A
    　 mm mm
    CPSB100 75/100 100
    CPSB150 150 150
    CPSB200 200 200
    CPSB300 300 300
    CPSB400 400 400
    CPSB500 500 500
    CPSB600 600 600

Accessories

Pendant channels

  • Type: PVC-U or steel - plastic coated.

Fixing pins

  • Ordering Code Material Size
    CPFB08 PVC-U M8
    CPFBS08 Steel M8

Nuts and bolts

  • Ordering Code Material Size
    CPNB0820 PVC-U M8×20
    CPNBS0820 Stainless steel M8×20
