Telephone Cables |  |
||||||||||
 |
||||||||||||
|
||||||||||||
Foam Skin Insulated & LAP Sheathed Jelly Filled Cables to IEC60708
| Cable Code | Number of Pairs | Nominal Sheath Thickness mm |
Nominal Overall Diameter mm |
Nominal Weight kg/km |
| 0.5mm Conductor, 0.9mm Insulated Wire | ||||
TP708-02YSF(L)2Y-10P05 |
10 |
1.5 |
10 |
108 |
TP708-02YSF(L)2Y-20P05 |
20 |
1.5 |
12 |
165 |
TP708-02YSF(L)2Y-30P05 |
30 |
1.5 |
13 |
226 |
TP708-02YSF(L)2Y-50P05 |
50 |
1.5 |
16 |
344 |
TP708-02YSF(L)2Y-70P05 |
70 |
1.5 |
18 |
458 |
TP708-02YSF(L)2Y-100P05 |
100 |
1.5 |
21 |
645 |
TP708-02YSF(L)2Y-150P05 |
150 |
1.8 |
25 |
939 |
TP708-02YSF(L)2Y-200P05 |
200 |
1.8 |
29 |
1224 |
TP708-02YSF(L)2Y-300P05 |
300 |
2.0 |
34 |
1787 |
TP708-02YSF(L)2Y-400P05 |
400 |
2.0 |
39 |
2352 |
TP708-02YSF(L)2Y-500P05 |
500 |
2.5 |
43 |
2897 |
TP708-02YSF(L)2Y-600P05 |
600 |
2.5 |
47 |
3469 |
TP708-02YSF(L)2Y-800P05 |
800 |
2.8 |
53 |
4553 |
TP708-02YSF(L)2Y-900P05 |
900 |
2.8 |
57 |
5129 |
TP708-02YSF(L)2Y-1000P05 |
1000 |
2.8 |
60 |
5666 |
TP708-02YSF(L)2Y-1200P05 |
1200 |
3.2 |
65 |
6732 |
TP708-02YSF(L)2Y-1500P05 |
1500 |
3.5 |
72 |
8348 |
TP708-02YSF(L)2Y-1800P05 |
1800 |
3.5 |
78 |
10011 |
TP708-02YSF(L)2Y-2100P05 |
2100 |
3.5 |
84 |
11609 |
| 0.6mm Conductor, 1.1mm Insulated Wire | ||||
| TP708-02YSF(L)2Y-10P06 | 10 | 1.5 | 11 | 139 |
| TP708-02YSF(L)2Y-20P06 | 20 | 1.5 | 13 | 218 |
| TP708-02YSF(L)2Y-30P06 | 30 | 1.5 | 15 | 302 |
| TP708-02YSF(L)2Y-50P06 | 50 | 1.5 | 18 | 467 |
| TP708-02YSF(L)2Y-70P06 | 70 | 1.5 | 21 | 639 |
| TP708-02YSF(L)2Y-100P06 | 100 | 1.8 | 25 | 894 |
| TP708-02YSF(L)2Y-150P06 | 150 | 1.8 | 30 | 1297 |
| TP708-02YSF(L)2Y-200P06 | 200 | 1.8 | 33 | 1707 |
| TP708-02YSF(L)2Y-300P06 | 300 | 2.0 | 40 | 2507 |
| TP708-02YSF(L)2Y-400P06 | 400 | 2.5 | 46 | 3315 |
| TP708-02YSF(L)2Y-500P06 | 500 | 2.5 | 51 | 4088 |
| TP708-02YSF(L)2Y-600P06 | 600 | 2.8 | 55 | 4860 |
| TP708-02YSF(L)2Y-800P06 | 800 | 3.2 | 63 | 6444 |
| 0.8mm Conductor, 1.4mm Insulated Wire | ||||
| TP708-02YSF(L)2Y-10P08 | 10 | 1.5 | 13 | 210 |
| TP708-02YSF(L)2Y-20P08 | 20 | 1.5 | 16 | 348 |
| TP708-02YSF(L)2Y-30P08 | 30 | 1.5 | 19 | 507 |
| TP708-02YSF(L)2Y-50P08 | 50 | 1.8 | 23 | 793 |
| TP708-02YSF(L)2Y-70P08 | 70 | 1.8 | 28 | 1081 |
| TP708-02YSF(L)2Y-100P08 | 100 | 1.8 | 32 | 1521 |
| TP708-02YSF(L)2Y-150P08 | 150 | 2.0 | 38 | 2240 |
| TP708-02YSF(L)2Y-200P08 | 200 | 2.5 | 43 | 2944 |
| TP708-02YSF(L)2Y-300P08 | 300 | 2.8 | 52 | 4355 |
| TP708-02YSF(L)2Y-400P08 | 400 | 2.8 | 60 | 5763 |
| TP708-02YSF(L)2Y-500P08 | 500 | 3.2 | 67 | 7158 |
Foam Skin Insulated, Double Steel Tape Armoured & LAP Sheathed Jelly Filled Cable to IEC 60708
| Cable Code | Number of Pairs | Nominal Inner Sheath Thickness mm |
Nominal Outer Sheath Thickness mm |
Nominal Overall Diameter mm |
Nominal Weight kg/km |
| 0.4mm Conductor, 0.75mm Insulated Wire | |||||
TP708-02YSF(L)2Y(DSTA)2Y-10P04 |
10 |
1.5 |
1.5 |
12.0 |
188 |
TP708-02YSF(L)2Y(DSTA)2Y-20P04 |
20 |
1.5 |
1.5 |
14.0 |
241 |
TP708-02YSF(L)2Y(DSTA)2Y-30P04 |
30 |
1.5 |
1.5 |
15.0 |
296 |
TP708-02YSF(L)2Y(DSTA)2Y-50P04 |
50 |
1.5 |
1.5 |
17.0 |
397 |
TP708-02YSF(L)2Y(DSTA)2Y-70P04 |
70 |
1.5 |
1.5 |
19.0 |
505 |
TP708-02YSF(L)2Y(DSTA)2Y-100P04 |
100 |
1.5 |
1.5 |
22.0 |
646 |
TP708-02YSF(L)2Y(DSTA)2Y-150P04 |
150 |
1.5 |
1.8 |
25.0 |
876 |
TP708-02YSF(L)2Y(DSTA)2Y-200P04 |
200 |
1.8 |
1.8 |
28.0 |
1091 |
TP708-02YSF(L)2Y(DSTA)2Y-300P04 |
300 |
1.8 |
1.8 |
32.0 |
1522 |
| TP708-02YSF(L)2Y(DSTA)2Y-400P04 | 400 | 1.8 | 2.0 | 37.0 | 1991 |
| TP708-02YSF(L)2Y(DSTA)2Y-500P04 | 500 | 2.0 | 2.0 | 43.0 | 2913 |
| TP708-02YSF(L)2Y(DSTA)2Y-600P04 | 600 | 2.0 | 2.5 | 46.0 | 3347 |
| TP708-02YSF(L)2Y(DSTA)2Y-800P04 | 800 | 2.5 | 2.5 | 51.0 | 4186 |
| TP708-02YSF(L)2Y(DSTA)2Y-900P04 | 900 | 2.5 | 2.8 | 54.0 | 4630 |
| TP708-02YSF(L)2Y(DSTA)2Y-1000P04 | 1000 | 2.5 | 2.8 | 56.0 | 5034 |
| TP708-02YSF(L)2Y(DSTA)2Y-1200P04 | 1200 | 2.8 | 2.8 | 61.0 | 5881 |
| 0.5mm Conductor, 0.9mm Insulated Wire | |||||
| TP708-02YSF(L)2Y(DSTA)2Y-10P05 | 10 | 1.5 | 1.5 | 14.0 | 227 |
| TP708-02YSF(L)2Y(DSTA)2Y-20P05 | 20 | 1.5 | 1.5 | 15.0 | 301 |
| TP708-02YSF(L)2Y(DSTA)2Y-30P05 | 30 | 1.5 | 1.5 | 17.0 | 381 |
| TP708-02YSF(L)2Y(DSTA)2Y-50P05 | 50 | 1.5 | 1.5 | 20.0 | 534 |
| TP708-02YSF(L)2Y(DSTA)2Y-70P05 | 70 | 1.5 | 1.5 | 22.0 | 681 |
| TP708-02YSF(L)2Y(DSTA)2Y-100P05 | 100 | 1.5 | 1.8 | 25.0 | 894 |
| TP708-02YSF(L)2Y(DSTA)2Y-150P05 | 150 | 1.8 | 1.8 | 30.0 | 1241 |
| TP708-02YSF(L)2Y(DSTA)2Y-200P05 | 200 | 1.8 | 1.8 | 33.0 | 1562 |
| TP708-02YSF(L)2Y(DSTA)2Y-300P05 | 300 | 2.0 | 2.0 | 40.0 | 2250 |
| TP708-02YSF(L)2Y(DSTA)2Y-400P05 | 400 | 2.0 | 2.5 | 47.0 | 3433 |
| TP708-02YSF(L)2Y(DSTA)2Y-500P05 | 500 | 2.5 | 2.5 | 51.0 | 4081 |
| TP708-02YSF(L)2Y(DSTA)2Y-600P05 | 600 | 2.5 | 2.8 | 55.0 | 4755 |
| TP708-02YSF(L)2Y(DSTA)2Y-800P05 | 800 | 2.8 | 3.2 | 62.0 | 6047 |
| TP708-02YSF(L)2Y(DSTA)2Y-900P05 | 900 | 2.8 | 3.2 | 65.0 | 6685 |
| TP708-02YSF(L)2Y(DSTA)2Y-1000P05 | 1000 | 3.2 | 3.5 | 68.0 | 7294 |
| 0.6mm Conductor, 1.1mm Insulated Wire | |||||
| TP708-02YSF(L)2Y(DSTA)2Y-10P06 | 10 | 1.5 | 1.5 | 15.0 | 270 |
| TP708-02YSF(L)2Y(DSTA)2Y-20P06 | 20 | 1.5 | 1.5 | 17.0 | 370 |
| TP708-02YSF(L)2Y(DSTA)2Y-30P06 | 30 | 1.5 | 1.5 | 19.0 | 482 |
| TP708-02YSF(L)2Y(DSTA)2Y-50P06 | 50 | 1.5 | 1.5 | 22.0 | 682 |
| TP708-02YSF(L)2Y(DSTA)2Y-70P06 | 70 | 1.5 | 1.8 | 25.0 | 888 |
| TP708-02YSF(L)2Y(DSTA)2Y-100P06 | 100 | 1.8 | 1.8 | 29.0 | 1191 |
| TP708-02YSF(L)2Y(DSTA)2Y-150P06 | 150 | 1.8 | 2.0 | 34.0 | 1645 |
| TP708-02YSF(L)2Y(DSTA)2Y-200P06 | 200 | 2.0 | 2.0 | 39.0 | 2161 |
| TP708-02YSF(L)2Y(DSTA)2Y-300P06 | 300 | 2.0 | 2.5 | 48.0 | 3617 |
| TP708-02YSF(L)2Y(DSTA)2Y-400P06 | 400 | 2.5 | 2.8 | 54.0 | 4573 |
| TP708-02YSF(L)2Y(DSTA)2Y-500P06 | 500 | 2.5 | 2.8 | 59.0 | 5510 |
| TP708-02YSF(L)2Y(DSTA)2Y-600P06 | 600 | 2.8 | 3.2 | 64.0 | 6396 |
| TP708-02YSF(L)2Y(DSTA)2Y-800P06 | 800 | 3.2 | 3.5 | 72.0 | 8215 |
| 0.8mm Conductor, 1.4mm Insulated Wire | |||||
| TP708-02YSF(L)2Y(DSTA)2Y-10P08 | 10 | 1.5 | 1.5 | 17.0 | 364 |
| TP708-02YSF(L)2Y(DSTA)2Y-20P08 | 20 | 1.5 | 1.5 | 20.0 | 548 |
| TP708-02YSF(L)2Y(DSTA)2Y-30P08 | 30 | 1.5 | 1.5 | 23.0 | 724 |
| TP708-02YSF(L)2Y(DSTA)2Y-50P08 | 50 | 1.8 | 1.8 | 28.0 | 1065 |
| TP708-02YSF(L)2Y(DSTA)2Y-70P08 | 70 | 1.8 | 1.8 | 32.0 | 1404 |
| TP708-02YSF(L)2Y(DSTA)2Y-100P08 | 100 | 2.0 | 2.0 | 37.0 | 1957 |
| TP708-02YSF(L)2Y(DSTA)2Y-150P08 | 150 | 2.0 | 2.5 | 46.0 | 3302 |
| TP708-02YSF(L)2Y(DSTA)2Y-200P08 | 200 | 2.5 | 2.5 | 51.0 | 4142 |
| TP708-02YSF(L)2Y(DSTA)2Y-300P08 | 300 | 2.8 | 2.8 | 61.0 | 5823 |
| TP708-02YSF(L)2Y(DSTA)2Y-400P08 | 400 | 2.8 | 3.2 | 68.0 | 7408 |
| TP708-02YSF(L)2Y(DSTA)2Y-500P08 | 500 | 3.2 | 3.5 | 75.0 | 9001 |
Fig 8 Foam Skin Insulated & LAP Sheathed Jelly Filled Cable to IEC 60708
| Cable Code | Number of Pairs |
Support Wire No. X Diameter mm |
Nominal Outer Sheath Thickness mm |
Nominal Cable Dimensions Height X Diameter mm |
Nominal Weight kg/km |
| 0.4mm Conductor, 0.75mm Insulated Wire | |||||
TP708-02YSF(L)2Y-10P04-SS |
10 |
7X0.9 |
1.5 |
16X8.0 |
136 |
TP708-02YSF(L)2Y-20P04-SS |
20 |
7X0.9 |
1.5 |
18X9.5 |
177 |
TP708-02YSF(L)2Y-30P04-SS |
30 |
7X1.2 |
1.5 |
20X10.9 |
252 |
TP708-02YSF(L)2Y-50P04-SS |
50 |
7X1.2 |
1.5 |
22X13.0 |
330 |
TP708-02YSF(L)2Y-70P04-SS |
70 |
7X1.2 |
1.5 |
24X14.7 |
404 |
TP708-02YSF(L)2Y-100P04-SS |
100 |
7X1.2 |
1.5 |
26X16.9 |
515 |
TP708-02YSF(L)2Y-150P04-SS |
150 |
7X1.6 |
1.5 |
30X19.8 |
760 |
TP708-02YSF(L)2Y-200P04-SS |
200 |
7X1.6 |
1.8 |
34X23 |
965 |
| 0.5mm Conductor, 0.9mm Insulated Wire | |||||
TP708-02YSF(L)2Y-10P05-SS |
10 |
7X0.9 |
1.5 |
17X8.9 |
158 |
TP708-02YSF(L)2Y-20P05-SS |
20 |
7X0.9 |
1.5 |
19X10.8 |
220 |
TP708-02YSF(L)2Y-30P05-SS |
30 |
7X1.2 |
1.5 |
22X12.4 |
309 |
TP708-02YSF(L)2Y-50P05-SS |
50 |
7X1.2 |
1.5 |
24X15.1 |
426 |
TP708-02YSF(L)2Y-70P05-SS |
70 |
7X1.2 |
1.5 |
26X17.1 |
530 |
TP708-02YSF(L)2Y-100P05-SS |
100 |
7X1.2 |
1.5 |
29X19.7 |
695 |
TP708-02YSF(L)2Y-150P05-SS |
150 |
7X1.6 |
1.8 |
35X25 |
1060 |
TP708-02YSF(L)2Y-200P05-SS |
200 |
7X1.6 |
1.8 |
38X28 |
1320 |
